L Bracket - U Channel and Enclosed 15W to 1000W
-
PAK650-PAK1000 Series
Features
- Universal AC Input with active PFC
- Programmavle Ouput Voltage (30%-105%)
- Programmavle Ouput Current (40%-105%)
- Forced current sharing for parallel operation
- Hight Efficiency up to 91%
- +5V/0.5A Auxiliary Output
- Intelligent LED Indicators
- 1U profile, Hight Power Density
- Power OK signal (Power good, logic low)
- Remote ON/OFF, Remote Sense function
- OVP, OLP, OTP, SCP, Fan Failure Protections
650 & 1000 Watts; 5V, 12V, 15V, 24V, 27V & 48VDC Outputs, Programmable Output Voltage (30-105%) & Current (40-105%), Universal AC Input, PFC, 1U Profile -
PAE800 Series
Features
- Universal AC Input with active PFC
- Programmavle Ouput Voltage (0%-105%)
- Programmavle Ouput Current (0%-105%)
- Hight Efficiency up to 93%
- +5V/0.5A or +8V/0.3A Auxiliary Output
- Intelligent LED Indicators
- 1U profile, Hight Power Density
- Forced current sharing for parallel operation
- Power OK signal (Power good, logic low)
- Remote ON/OFF, Remote Sense function
- OVP, OLP, OTP, SCP, Fan Failure Protections
- Constant current Limiting
- Optional RS232 Function
- Builit-in I²C Serial Data Bus
800 Watts, 12V, 15V, 24V, 30V, 36V, 48V & 60VDC Outputs, Programmable Output Voltage & Current (0-105%), Universal AC Input, PFC, I"C Serial Data Bus, Optional RS232, 1U Profile -
JB250 and JB250D Series
Features
- AC Input Range Auto-Selectable
- Hight Power Density in a 1U Height.
- Single Output Voltages from 2~60VDC
- Dual Output Voltage Combinations of 3.3 / 5 / 12 / 24 & 48V
- Approved to UL / TUV / CB / CE
- U-Chassis & Enclosed with built-in fan Mechanical Options
- Peak Power 600W (single output versions-limited duty cycle)
JB250D Series up to 250 Watts, Dual Output, U Channel or with Fan Cover -
JB301-JB301D Series
Features
- Power Factor Corrected to EN61000-3-2 class D
- Single Output Voltage from 2 ~ 60VDC
- Dual Output Voltage Combinations of 5 / 12 24 & 48V
- High Power Density in a 1U Height.
- Approved to UL / TUV / CB / CE
- 4 Mechanical Options
- Full Range AC Input
JB301-JB301D Series; 240-300W; Universal AC Input; Active PFC; Single and Dual Outputs; 4 Mechanical Options -
JB320 & JB320D Series
Features
- Power Factor Corrected to EN61000-3-2 class A
- Single Output Voltage from 2 ~ 60VDC
- Dual Output Voltage Combinations of 5 / 12 24 & 48V
- High Power Density in a 1U Height.
- Approved to UL / TUV / CB / CE
- 4 Mechanical Options
- AC Input Range Auto-Selectable
JB320 & JB320D Series; up to 320 Watts; Single & Dual Outputs; U Channel; Enclosed with Fan -
JB400 & JB400D Series
Features
- Active Power Factor Correction meets EN61000-3-2 Class D
- Optional Medical Approved Versions (M)
- Optional Active Current Sharing (I)
- Peak Power up to 700W with 500μS Duty Cycle
- U Chassis or Enclosed with Integral Fan
- 1U Height with High Power Density of 6.25W per Cubic Inch
- Current Monitoring and Remote Voltage Adjustment (Remote Margin)
- Single & Dual Output Models
JB400 & JB400D Series; 400 Watts; Universal AC Input; Active PFC; Single and Dual Outputs -
VCS Series
Features
- Chassis Mount Industrial Supplies
- -25 °C to +70 °C Convection Cooled
- Class B Conducted & Radiated Emissions
- Output Voltages from 5 V to 48 V
- <0.5 W No Load Input Power
- Low Cost
-
ECC100 Series
Features
- -40 ºC to +75 ºC Operation
- 100 W - Baseplate Cooled
- High Efficiency Resonant Topology
- Screw Terminals Available
- 5V Standby Output
- Remote On/Off & Power OK Signal
- 3 Year Warranty
-
UCP180 Series
Features
- 120W convection cooled -40°C to +70°C operation
- 180W with 10CFM forced air cooling -20°C to +70°C operation
- 4.3” x 2.5” footprint
- Low 1.16” profile U channel construction
- ITE & Medical (BF, 2 x MOPP) approvals
- Class B conducted & Class A radiated emissions
- Input voltage range 85 to 264VAC
- Output voltages from 12 to 48VDC
- No load input power <0.5W
- High efficiency, up to 94%
- 12V/0.5A fan output
- -40°C to +70°C operating temperature
- Full power to +50°C
- MTBF 300 khrs (MIL-HDBK-217F, +25°C GB)
- 3 year warranty
The UCP180 series is designed to minimize the no load power consumption and maximize efficiency to facilitate equipment design to meet the latest environmental legislation. Approved for medical and ITE applications, this range of single output AC/DC power supplies are packaged in an ultra-low profile 1.16” height with a foot print of just 2.5” by 4.3”. The UCP180 provides up to 180 W force-cooled or 120 W convection-cooled leading to very high power densities of 14.2 W/in3 or 9.4 W/in3 respectively. A 12 V, 500 mA fan supply is included in the design. The power supply contains two fuses and low leakage currents as required by medical applications and is safety approved to operate in a 70 °C ambient. The low profile and safety approvals covering ITE and medical standards along with conducted emissions to EN55011/32 level B enable the versatile UCP180 series to be suitable for a vast range of applications. -
UCP225 Series
Features
- Low 1.18” Profile U Channel Construction
- -40 °C to +70 °C Operation
- 3.12” by 5.0” Footprint
- 150 W Convection/ 225 W Forced Cooled Ratings
- Optional 5 V Standby and Remote On/Off
- 12 V Fan Output
- Medical and ITE Approvals
- High Efficiency, up to 95%
- Less than 0.5 W No Load Input Power
The UCP225 series is designed to minimize the no load power consumption and maximize efficiency to facilitate equipment design to meet the latest environmental legislation. Approved for medical and ITE applications, this range of single output AC/DC power supplies are packaged in an ultra-low profile 1.18” height with a foot print of just 3.12” by 5.0”. The UCP225 provides up to 225 W force-cooled or 150 W convection-cooled leading to very high power densities of 12.2 W/in3 or 8.1 W/in3 respectively. A 12 V, 500 mA fan supply is included in the design which can also be delivered with an optional 5 V/2 A standby output. The power supply contains two fuses and low leakage currents as required by medical applications and is safety approved to operate in a 70 °C ambient. The low profile and safety approvals covering ITE and medical standards along with conducted emissions to EN55011/22 level B allow the versatile UCP225 series to be used in a vast range of applications.
Total of 33 results
