• Features

    • Regulated single & dual outputs from 3.3V to 30VDC
    • Wide 4:1 input range
    • Chassis mount with optional DIN rail clip
    • UL62368-1 safety approvals
    • EN55032 class A
    • Remote On/Off & voltage trim function
    • 3kVDC isolation
    • -40°C to +100°C operating temperature
    • Full power to 80°C
    • 3 year warranty

    PDF

The DTJ series of chassis mount DC-DC power supplies allows for easy and convenient integration into a variety of industrial and commercial applications. The DC-DC power solution is constructed using lightweight materials and includes features such as short circuit protection, input reverse polarity protection and soft start. The wide input range covers nominal voltages of 12V, 24V and 48V.
