Open PCB versions from 5 watts to 350 watts
-
EML30 Series
Features
- Compact Size
- Medical Approvals
- Single Outputs from 3.3 to 48 V
- PCB Mount, Open Frame & Chassis Mount
- Encapsulated PCB & Chassis Mount
- Class II
- Peak Load Capability
- 3 Year Warranty
The EML30 is a series of open frame and encapsulated AC-DC single output power supplies
designed for medical applications. The series provides a number of flexible mechanical options
including PCB mount, open frame, chassis mount with screw terminals and a DIN Rail option. With
approvals to world-wide medical safety standards, compliance with class B for both conducted and
radiated emissions and a 130%, 30s peak load capability, these class II isolation parts benefit
system designers with easy integration into the latest healthcare products and applications. -
FCS40 Series
Features
- 40 W Convection Rating
- 2” by 3” Footprint
- Low 1.04” Profile
- High Efficiency
- Medical, ITE and Household Appliance Approvals
- Class I & Class II Installations
- High Power Density
- Less than 0.3 W No Load Input Power
- 3 Year Warranty
The FCS40 series is designed to minimize the no load power consumption and maximize efficiency
to facilitate equipment design to meet the latest environmental legislation. Approved for medical and
ITE applications in either Class I or Class II installations, this range of single output AC-DC power supplies
are packaged in a low profile 1.04” height with a foot print of just 2” by 3”. The FCS40 provides up to
40W convection-cooled over the full 90-264 VAC input range, and operates down to 80 VAC with minimal
de-rating. The power supply features two AC line fuses and low leakage currents required by medical applications. The low profile, low noise and safety
approvals covering ITE and medical standards allows the versatile FCS40 series to be used in a wide range of applications. -
FCS60 Series
Features
- 60 W Convection Rating
- 2” by 4” Footprint
- Low 1.04” Profile
- High Efficiency
- Medical, ITE and Household Appliance Approvals
- Class I & Class II Installations
- High Power Density
- Less than 0.3 W No Load Input Power
- 3 Year Warranty
The FCS60 series is designed to minimize the no load power consumption and maximize efficiency
to facilitate equipment design to meet the latest environmental legislation. Approved for medical and
ITE applications in either Class I or Class II installations, this range of single output AC-DC power supplies
are packaged in a low profile 1.04” height with a foot print of just 2” by 4”. The FCS60 provides up to
60W convection-cooled and operates down to 80 VAC. The power supply features two AC line fuses and
low leakage currents required by medical applications. The low profile, low noise and safety approvals covering ITE and medical standards allows the
versatile FCS60 series to be used in a wide range of applications. -
ECF40
Features
- 40W convection cooled
- 76.2 x 38.1mm (3” x 1.5”) footprint, 28.0mm profile
- Regulated single outputs 12 to 48VDC
- Input range 80 to 264VAC
- Medical (2 x MOPP) & ITE approvals
- Class I & Class II installations
- Less than 0.15W no load input power
- 3 year warranty
The ECF40 series is designed to minimize the no load power consumption and maximize efficiency to facilitate equipment design to meet the latest environmental legislation. Approved for medical (2 x MOPP) and ITE applications in either Class I or Class II installations and has two AC line fuses and low leakage currents required by medical applications.
This range of single output AC-DC power supplies are packaged in a low profile 28.0mm height with a foot print of just 76.2 x 38.1mm. The ECF40 provides up to 40W convection-cooled over the full 90-264VAC input range, and operates down to 80VAC with minimal de-rating. The low profile, low noise and safety approvals covering ITE and medical standards allows the versatile series to be used in a wide range of applications. -
VCB60
Features
- 60W convection cooled
- 4” x 2” footprint, low 1.01” profile
- Low cost
- ITE & household appliance approvals
- Overvoltage category III
- EN55035 and EN55024 immunity standard
- Class I operation
- Input voltage range 90 to 305VAC
- Regulated single outputs from 5 to 54VDC
- Efficiency to 90%
- Short circuit, overvoltage & overload protection
- -10°C to +70°C operating temperature
- Full load to +50°C
The VCB60 is a series of open frame AC-DC single output power supplies designed for low cost ITE, industrial and domestic applications. With approvals to world-wide safety standards including ITE and Household, compliance with class B for conducted and radiated emissions, this series benefit system designers with easy integration into a wide range of applications. A wide input range of 90-305VAC and approval to overvoltage category III (OVC III) eases installation in building wiring systems. -
LCE80
Features
- 80W convection cooled
- 4” x 2” footprint
- Constant voltage, constant current operation
- Suitable for lighting and display applications
- ITE & lighting safety approvals
- 90 to 305VAC operation
- Class I & class II operation
- Harmonic currents class C
- LPS approval for 12V and above
- Less than 0.5W no load input power
- -40˚C to +70˚C operating temperature
- 3 year warranty
With an excellent power density, constant voltage and constant current operation, harmonic currents class C for loads of 50W and above, low power source approval, class I & class II operation and a wide input voltage range of 90 to 305VAC, the convection cooled 80W LCE80 4” x 2” open frame power supply meeting the latest environmental legislation provides a solution for wide ranging applications in lighting, display, industrial electronics and ITE applications.
-
FCB100
Features
- 100W fan cooled
- 80W convection cooled
- 4” x 2” footprint, low 1.25” profile
- Class I & Class II applications
- Medical (BF), ITE & household approvals
- Class B conducted & radiated emissions
- Input Range 80 to 264VAC
- <0.3W no load input power
- Regulated single outputs from 12 to 48VDC
- Short circuit, overvoltage & overload protection
- -25°C to +70°C operating temperature
- 3 year warranty
The FCB100 is a series of open frame AC-DC power supplies designed for medical devices (including BF), industrial electronics, ITE & household applications. The FCB100 is compliant with class B conducted & radiated emissions, can be used in both class I & class II installations and the wide 80VAC to 264VAC operating input range makes it ideal for both home healthcare applications and in hospital use.
With both convection and fan cooled ratings, extremely low emissions and safety & EMC certification for global use, the FCB100 benefits system designers with easy integration into a wide range of applications across multiple end markets -
ECP130 Series
Features
- 100 W Convection/130 W Forced-cooled Ratings
- 2” by 3” Footprint
- Low 1.1” Profile
- High Efficiency, up to 95%
- Medical and ITE Approvals
- High Power Density
- Less than 0.5 W No Load Input Power
- 3 Year Warranty
The ECP130 series is designed to minimize the no load power consumption and maximize efficiency to facilitate equipment design to meet the latest environmental legislation. Approved for medical and ITE applications, this range of single output AC-DC power supplies are packaged in a low profile 1.1” height with a foot print of just 2” by 3”. The ECP130 provides up to 130 W force-cooled or | 100 W convection-cooled leading to very high power densities of 19.7 W/in3 or 15.1 W/in3 respectively. The power supply contains two fuses and low leakage currents as required by medical applications and is safety approved to operate in a 70 °C ambient. The low profile and safety approvals covering ITE and medical standards along with conducted emissions to EN55011/32 level B allow the versatile ECP130 series to be used in a vast range of applications. -
ECP180 Series
Features
- Low 1” Profile
- High Power Density
- 2.0” by 4.0” Footprint
- 120W Convection-cooled Rating
- 180W Force Cooled Rating
- Medical & ITE Approvals
- Class I and Class II Applications
- High Efficiency, up to 94%
- Less than 0.5W No Load Input Power
- Built-In Fan Supply
- Low Earth Leakage Current
- 5000m Operating Altitude
-
ECP225
Features
- 225W fan cooled 150W convection cooled
- 127.0 x 63.5mm (5” x 2.5”) footprint,
- 25.4mm profile
- Regulated single outputs 12 to 48VDC
- Input range 85 to 264VAC
- High efficiency – up to 95%
- Medical (2 x MOPP) & ITE approvals
- 4.0kVAC input to output isolation
- <0.5W no load input power
- 12V/0.5A fan supply
- -20°C to +70°C operating temperature
- Full load to +50°C
- 3 year warranty
The ECP225 series has been designed to minimise the no load power consumption and maximise efficiency in order to facilitate equipment design to meet the latest environmental legislation. Approved for medical (2 x MOPP), ITE and industrial electronics applications, this range of single output AC-DC power supplies are packaged in an ultra-low profile 25.4mm height with a foot print of just 127.0 x 63.5mm (5.0” x 2.5”). The power supply contains two fuses and low leakage currents as required by medical applications and is safety approved to operate in a +70°C ambient, a 12VDC 500mA fan supply is included in the design.
The low profile and safety approvals covering ITE and medical standards along with conducted emissions meeting EN55011/32 level B allow the versatile ECP225 series to be used in a vast range of applications.
